ZT-1112B Digital Display Liquid Density Tester Liquid Densitometer
Product overview:
Digital display liquid density meter mainly for: chemical solution, modern energy, fuel oil, fine chemicals, chemical reagent, chemical research laboratory. Measurement of the density of adaptation in the field of quality management, formulation, cost control, density of etc. Using the Archimedes principle, meet with the specification of GB/T 611, GB/T11540, GB/T12206, GB/T5518, and other standards.
Digital display liquid density tester, using Archimedes principle combines with the modern electronics technique, direct digital display density, high measuring accuracy, stable and durable. Compared with the traditional method, the Wechsler scales Pycnometer method, the machine operation more simple, and not affected by external factors and temperature, can realize the fast and precise measurement.
Digital display liquid density tester is also suitable for measuring: solvent, adhesive, paint, asphalt, ink, resin, chemical oil, edible oil, food additive, beverage, dairy products.
Functions:
1. Operation in one step, easy to realize multiple continuous rapid test
2.Any solution can be fast measurement
3.Digital display, high measuring accuracy, simple operation, stable and durable
4.Sample density measurement at room temperature to 100 DEG C temperature condition value
5.Convenient sampling, the sample is only 50CC
6.Without debugging and operation of Webster‘s balance method, Pycnometer method cumbersome
7.The specific gravity of liquid can be matched with a constant temperature water tank operation, measuring the required temperature
8.Measuring cup is easy to clean, not by pycnometer small caliber restrictions, can be repeatedly used. At the same time, also can use disposable measuring cup
9.Volatile liquid, corrosive liquid, viscous liquid, strong acid and strong alkaline liquid can quickly measure (purchase related accessories)
10.Containing RS-232C communication interface, convenient connection between the PC and the printer, optional DE-40 printer print measurement data
11.Configuration special windproof dustproof cover, combination is convenient, durable
The measurement procedures:
1.The filled with sample measuring cup placed on the measurement of placing plate, after deducting the hook weight.
2.Using the hook will be standard weight hanging and completely submerged in the liquid to be measured, display of density value.
Specification:
|
Density accuracy |
0.001 g/cm3 |
|
Density range |
0.001—99.999g/cm3 |
|
Measurement category |
a: mobile liquid, viscous liquid, volatile liquid, corrosive liquids, high temperature liquids, suspension liquid, a liquid ... emulsified state and other liquids b: Similar alcohol, flux, flavor, blood, sodium chloride, glycerol, electrolyte, diesel oil, the refrigerant, hydrofluoric acid, dichloromethane, diethyl ether, sulfuric acid, etc ... liquid state measurement Jieke |
|
The measuring principle |
Archimedes displacement method |
|
Measurement mode |
Group 1 |
|
Test time |
Immediate measure |
|
Memory Mode |
Dynamic Memory |
|
results |
Density values |
|
Measuring the proportion of aircraft |
Stainless steel frame specific gravity measurement |
|
Function Setting |
Temperature setting, the solution density is set, the set standard value and the measured weight by weight of the water weight values |
|
Correction mode |
A single bond automatic correction, the automatic detection function |
|
Measurements uthentication |
Distilled water verification |
|
Output |
RS-232C standard communication interface to facilitate the test data output and print |
|
Standard Accessories |
1.Host 2.measure placing plate 3.standard liquid measurement components 4.forceps 5.thermometer 6.100G weights 7.wind dust cover 8.measuring stand 9.a power transformer DE-20A standard liquid measurement component set: Includes two stainless steel hooks, weights a standard glass, stainless steel weights a measuring cup 2 |
|
Optional Accessories |
1. printer 3. standard liquid measurement components |
|
Power |
AC~220V / 50HZ |
