Applicable Range :
Used for testing the vertical permeability of geo textiles and composite materials.
Relevant Standards :
GB/T15789,JTG E50,SL/T235,ISO11058,ASTM D4716
Technical parameters :
1.Max.pressure difference of water head:250mmH O(2450pa)
2.Value point of water level :1mm
3.Internal diameter of clamp:50±0.5mm
4.Testing sample thickness: ≤20mm
5.Time control: 0~99.99 secs
6.Graduated cylinder:1000ml(testing accuracy:10ml)
7.Thermometer scope:0~50°C( accuracy: 0.1°C)
8.Power source:AC220V±10% 50Hz 100W
9.External dimension:400×500×850mm
10.Weight:45kg
