Purpose:
Cutting materials: non-woven fabric, fireproof fabric, melt blown fabric, roll paper, plastic film, pearl cotton, leather, aluminum foil, PVC, PE industrial materials, chemical materials, composite materials, etc
Features:
1. Use magnetic powder brake to control tension
2. Variable frequency speed regulation and adjustable cutting speed
3. Standard rice marker configuration
4. Adopting dual pneumatic expansion shafts for smooth winding
5. Optoelectronic correction for anti deviation cutting
6. The width and number of knives can be customized according to requirements
Parameters:
|
Inner width |
800-4000mm |
|
Winding motor |
3.0KM pure copper motor |
|
Knife shaft motor |
1.5KM pure copper motor |
|
Maximum unwinding diameter |
1.25 meters |
|
Maximum unwinding width |
1.5 m, support custom |
|
Maximum winding diameter |
0.6 m, support custom |
|
Winding method |
A/B dual axis cross winding (active winding) |
|
Winding and unwinding air expansion shaft |
3 inches (suitable for inner diameter of 75-78mm paper cylinder, or customized according to customer requirements) |
|
Minimum cutting width |
20mm (other sizes can be adjusted simultaneously) |
|
slitting knives |
10 sets of straight/round |
|
Cutting accuracy |
± 0.05mm |
|
Adjustable cutting speed |
5-120m/min |
|
Cutting thickness |
15-1000g/m2 |
|
Rack |
8cm * 10cm * 5mm square tube welding |
|
Total power |
5.5KM |
|
Power supply |
AC380V50HZ |
