Technical specification:
|
Model |
ZT-500 |
ZT-600 |
ZT-900 |
ZT-2000 |
|
Voltage |
1P/220v |
1P/220v |
3P/380v |
3P/380v |
|
Motor |
60kw |
60kw |
60kw |
60kw |
|
Power |
5.4kw |
6.4kw |
12kw |
60kw |
|
Max Pressure |
1.5kg/cm² |
1.5kg/cm² |
4kg/cm² |
6kg/cm² |
|
Fusing Width |
500mm |
600mm |
900mm |
2000mm |
|
Fusing time |
10-30sec |
10-30sec |
10-30sec |
10-30sec |
|
Temperature |
0-230C |
0-230C |
0-230C |
0-230C |
|
Weight |
145kg |
165kg |
350kg |
1000kg |
|
Dimension |
175*103*128cm |
185*113*128cm |
280*143*130cm |
480*270*160cm |
Feature:
1. Continuous fusing system increases the productivity.
2. Equipped with the wheels for convenient mobility.
3. PCB and micro switch control the upper and lower belts automatically and extends duration of the belt.
4. Pressure rollers are made by silicone,which ensure the power of pressure giving is stable and equal.
5. Electronic temperature constant temperature control system, temperature accurately.
6. There are 9 heaters to distribute the heat evenly and can be used to all fabrics.
7. With the cooling fan and mesh conveyor belt,which has the best cooling effect.
8. Equipped with automatic cooling timing shutdown system.
9. With pneumatic cylinder pressure system offers better bonding result.
10.Special-designed clean rod to clean the belt completely,and it is easy for replacement once the rod gets dirty.
11.With frequency conversion mechanic to control speed, running smoothly and more energy saving.
12.Optional:Basket of cloth/Automatic feeding machine;Winding machine/Infrared edge cloth rolling machine.
