Environment Test Chamber

Technical parameters:

1. Volume: 5L

2. Temperature range: --300 ℃

3. Temperature fluctuation: ± 0.02 ℃

4. Opening size: 180 x 140mm2

5. With a pipe rack (made of stainless steel, opening 12 of the hole diameter 16mm)

6. The instrument Dimensions: 240 x 370 x 400mm3

7. Instrument total weight: 18KG

Main features :

Precision low-temperature thermostat tank using microcomputer intelligent control system, with over-temperature protection, temperature sensor abnormal protection function, to ensure test security, touch button operation can be quickly and accurately set temperature, easy to operate.

Computer system to facilitate error correction display temperature and actual temperature, temperature correction resolution of up to 0.01 ℃, make digital temperature value is accurate. PID parameters of a particular user can reset their own, and has self-tuning PID function.

Precise temperature control, advanced within the circulatory system to make it work fast constant temperature bath.

Main application:

Precision temperature water sump suitable for electronic detection, and high chemical reactions, high temperature distillation, and other warm-blooded precision semiconductor industry requires the development of low-temperature test equipment, with tank temperature and make uniform, more accurate temperature control and so smart. Also as ordinary thermometers and other temperature measuring instruments manufacturing calibration purposes.
