The torque test meter is suitable for the torque test of various products, such as electric screwdriver, air screwdriver, motor, toy, bottle cap, hardware and so on.
Torque unit conversion: 1n. M ≈ 10kgf. Cm ≈ 8.85 LBF. In ≈ 142 ozf. In
|
Model |
7017C-10 |
7017C-20 |
7017C-50 |
7017C-100 |
7017C-250 |
|
Measuring range |
0.05~10.00kgf.cm 0.005~1.000N.m |
0.5~20.0kgf.cm 0.05~2.00N.m |
0.5~50.0kgf.cm 0.05~5.00N.m |
0.5~100.0kgf.cm 0.05~10.00N.m |
5~250kgf.cm 0.5~25.0N.m |
|
Resolution |
0.01kgf.cm 0.001N.m |
0.1kgf.cm 0.01N.m |
0.1kgf.cm 0.01N.m |
0.1kgf.cm 0.01N.m |
1kgf.cm 0.1N.m |
|
Measurement mode |
PEAK, TRACK |
||||
|
Unit |
kgf.cm , N.m , lbf.in |
||||
|
Sampling rate |
1000Hz |
||||
|
Battery type |
Large capacity environmental protection lithium battery |
||||
|
Charging time |
About 6 hours |
||||
|
Usage time |
Full charge for about 50 hours |
||||
|
Battery life |
Cycle charge about 1000 times |
||||
|
Charger specification |
Input: AC110V~220V 50/60Hz, output: 9V 0.6A |
||||
|
Work environment |
Temperature:-10℃~40℃ humidity:35%~65%RH |
||||
