Principle:
Heat Seal Film Shrinkage Tester is composed of upper and lower heat sealing jaws. Before the test, preset the heat seal temperature, pressure and dwell time value, place the specimen in between the upper and lower jaws, and then press start button. The whole sealing process can be finished automatically.
Standards: ASTM F2029, QB/T 2358, YBB 00122003
Introduction:
Plastic Peeling Hot Tack Test Machine is based on the heat sealing method, and is professionally applicable to the determination of heat seal temperature, dwell time, and the pressure of heat seal of various composite films to guide industrial production. The instrument adopts the specially designed heat sealing jaws, which completely conform to multiple national and international standards.
Digital P.I.D. temperature control technology ensures the preset temperature to be reached rapidly without any fluctuation.
Wide range control of temperature, pressure and time that meet various test conditions
Manual or pedal switch, as well as anti-scald design provides convenient and safe operating environment.
The instrument is controlled by micro-computer with LCD, PVC operation panel and menu interface
Professional software supports remote operation for convenient data saving, exporting, and printing.
Technical Specifications:
|
Sealing Temperature |
Room temperature ~ 250°C |
|
Accuracy |
±1°C |
|
Dwell Time |
0.01~9999.99s |
|
Sealing Pressure |
0 ~ 0.7MPa |
|
Sealing Area |
300mm x 10mm (customization available) |
|
Heating Mode |
Single heating or double heating; The upper and lower sealing knives can be switched separately and the temperature can be controlled separately |
|
Gas Supply Pressure |
≤0.7MPa |
|
Size |
bout 550 mm x 330 mm x 460mm |
|
Power |
AC 220V 50Hz |
|
Net Weight |
35 Kg |
|
Test mode |
Manual mode (controlled by foot switch) Automatic mode (controlled by adjustable time delay relay) |
|
Standard configuration |
host + foot switch + air supply line + air filter + power line + technical documents |
