Technical indicators:
| Measuring range | 0-5mm |
| Resolution | 0.001mm |
| Display mode | digital display |
| Contact area | (200 ± 5) mm2 |
| Contact pressure | (100 ± 10) kPa |
| Parallelism | ≤0.005mm |
| Dimensions | 170 (L) x 130 (W) x 150 (H) mm |
| Weight | about 5kg |
| Standard configuration | host, dial gauge |
Application:
A test instrument for the thickness of paper, cardboard, and some sheet materials with a certain degree of tightness. The instrument for measuring the thickness of paperboard is an indispensable testing tool for paper making enterprises, packaging manufacturers and quality inspection departments.
Test principle:
The paper or paperboard is subjected to a certain pressure between the two measuring surfaces to measure the distance between the two surfaces of the paper or paperboard, and the result is expressed in millimeters or micrometers.
Product features:
1. Clear any position to facilitate differential measurement
2. With ON/OFF switch key
3. Measurement system can be converted
Executive standard: GBT 451.3, QBT 1055, ISO 534
