Paper and Packaging Test Machine

Application:

Urine Diaper Sanitary Napkin Water Permeability Tester is used for testing external sanitary wares for women‘s menstrual period (sanitary napkins), non-menstrual (sanitary pads) and baby diapers, which are composed of outer covering material, inner absorbent layer, anti-seepage base film, etc. Permeability test for specific test solutions. The amount of infiltration is an important parameter describing the hygienic permeability.

Introduction:

The amount of infiltration is an important parameter for detecting the permeability of a diaper/sanitary napkin.

Permeability is an important technical parameter for the permeability of baby diapers, baby diapers, adult diapers and diapers, and paper diapers (care pads). It includes slippage, back seepage and leakage. Slippage refers to the volume of a certain amount of test solution that is not absorbed when flowing through the surface of the inclined sample, in ml; the amount of back-seepage refers to the test of returning the surface layer under a certain pressure after the sample absorbs a certain amount of test solution. The mass of the solution, the unit of g; the leakage amount refers to the mass of the test solution passing through the anti-leakage base film, in units of g, after a certain amount of the test solution is absorbed by the sample.

Standard:

GB/T 8939-2008 "Sanitary napkins (including sanitary pads)"

GB/T 28004-2011 "diapers"

QB/T 2493-2000 diaper (with diapers/pads)

Features:

One instrument performs two different modes of testing: sanitary napkins (10°) and diapers (30°).

Sanitary napkin test delivery accessories:

1 100ml beaker, 1 ml 10ml pipette

Diaper test equipment distribution accessories:

One 100 ml and 10 ml graduated cylinders, one 500 ml beaker and four stainless steel clips.
