Applicable materials:
HDP, LDPE, LLDPE, blown film grade PP+masterbatch, filler masterbatch, plastic additives, functional masterbatch.
Product parameters:
|
Single screw micro blown film machine |
|
|
Name |
Micro blown film machine |
|
Screw diameter |
16mm |
|
Length to diameter ratio |
1:30 |
|
Screw speed |
0-100rpm variable frequency speed regulation |
|
Heating power |
3KW |
|
Main motor servo motor |
750W |
|
Reduction ratio |
1:25 |
|
Mold diameter |
20mm |
|
Weight |
50kg |
|
Inflating gas |
external air compressor source |
|
Cooling gas |
Micro fan cooling |
|
Traction roller size |
diameter 80*L200mm |
|
Traction motor |
90W |
|
Traction winding speed |
0.5~8mm/min |
|
Adjustable winding motor |
10W |
|
Film bending diameter |
40~100mm |
|
Controller |
PLC programmable color touch screen, human-machine interface operating system, extrusion process can be dynamically displayed and monitored |
Characteristic:
1. PLC programmable color touch screen, human-machine interface operating system, movable extrusion process
State display and monitoring
2. Blow molded products are directly wound up.
3. Stainless steel feeding hopper.
4. Both the screw and the barrel are made of 38CrMoAl alloy steel, and the surface is treated with processes such as nitriding and ultra precision honing.
