Features of small injection molding machines:
1. Adopting color screen full computer control circuit
2. Using "Hayeur " anti-corrosion material pipe group
3. Adopting Taiwan‘s "Oil Research" or "Dongfeng" solenoid valves
4. Using Japanese "NOK" oil seal
5. Adopting "Earth" hydraulic motor with high torque
6. Adopting a spiral circulation cooler to ensure good heat exchange, low oil temperature, long service life of oil pressure parts, and stable molding
7. Adopting a direct pressing mold locking system, easy to operate, fast and safe mold opening and closing speed, and equipped with a low-pressure protection mold
8. Adopting Taiwan Yangming proximity switch
9. Adopting Taiwan Geely dual proportional valve
10. Adopting Taiwan‘s "Yongling" brand oil pump
11. Using the Fuji start switch button from Japan
12. Using "Great Wall" VG-68 # anti wear hydraulic oil
13. Adopting Omron protection switch
14. Using double-layer steel mesh high-pressure oil pipes
15. The minimum mold thickness of the machine is determined according to customer needs
|
Ejection system |
|
|
Screw diameter |
26Mm |
|
Ejection pressure |
1750Kg/cm2 |
|
Theoretical injection capacity |
40/60 |
|
Ejection rate |
52/1.8cm2 |
|
Ejection rate |
40G/sec |
|
Screw stroke |
110mm |
|
Screw speed |
0-215Rpm |
|
Contact force of nozzle |
4.5Tons |
|
Nozzle stroke |
150mm |
|
Number of temperature control sections |
3+1 |
|
Locking system |
|
|
Locking force |
20Tons |
|
Template size |
360 * 300Mm |
|
Mold column spacing |
250 * 200Mm |
|
Minimum mold thickness |
100/40Mm |
|
Mold opening stroke |
215Mm |
|
Maximum mold opening distance |
255/315Mm |
|
Ejection force |
1.3Tons |
|
Ejection stroke |
35Mm |
|
Oil pressure power system |
|
|
Maximum hydraulic pressure |
140 |
|
Pump blade output |
26L |
|
Operating oil volume |
80L |
|
Cooling water consumption |
400-600LH |
|
Motor power |
2.2 (3HP) kw |
|
Electric heating capacity |
2kw |
|
Total electricity consumption |
4.2kw |
