Characteristics:
1.Pioneered the use of laser angle measurement technique, accuracy, high reliability, and to overcome the angular range of small photovoltaic technology drawbacks. The angular range up to 0 ~ 180 ℃.
2.Adopt stepper motor, lift heavy automatic turn intelligent test; easy operation.
3.unique patented technology, namely the slow recovery angle test specimen flap truer.
4.Microcomputer control, big-screen film LCD.
5.The instrument practicality, stability, accuracy leading;
6.The instrument is compact and reasonable design, excellent performance, clapping rate is very low.
7.Test reports directly from the printer output.
Application: Test the crease-reeovery performance of cotton, wool, linen, solk, chemical, fabrics or mixed textiles.
Standards: GB/T 3819, ISO 2313
Technical Parameters:
Pressure loading |
10N |
Pressured time |
5min±5S |
Pressured area |
40×15mm |
Accuracy of measuring angle |
0-180°±1° |
Work Position |
10 |
Dimensions |
L830×W440×H550 |
Weight |
80kg |
Power |
AC220V |
