Application:
The fiber fineness meter is used for three kinds of fiber diameter measurement, cross-sectional analysis, and textile composition content measurement.
Standard:
GB/T10685 FZ/T30003 SN/T0756 AATCC20A, etc.
Technical Parameters:
|
Working mode |
manual measurement, automatic measurement, multi-point measurement; automatic statistical analysis, report printing, photo printing |
|
Instrument structure |
computer, industrial camera, microscope, printer |
|
Measuring range |
1-200μm |
|
Measurement accuracy |
0.1μm |
|
Power source |
AC220V 50Hz 100W |
|
Dimensions |
640×560×600mm |
|
Weight |
22kg |
Features:
1. The cross-section measurement complies with AATCC 20A-1995 fiber quantitative analysis regulations;
2. It is used to observe the cross-sectional shape of various chemical fibers, shaped fibers and hollow fibers and measure the cross-sectional area;
3. Test the profile of profiled fibers;
4. The fiber content of various blended products can be obtained by analyzing the single fiber transverse morphology and area measurement in the blended products;
5. Using professional analysis software, data and reports are exported in EXCEL, and standard reports are provided.
