Introduction:
The experimental material is placed in the mold, parallel to the heating plate of this product, with a certain temperature and pressure, so that the experimental material is formed for production reference.
Features:
1. The machine is small in size and full in function, stable in temperature and low in noise. Easy to operate, save material, accurate temperature.
2. High precision, high wear resistance guide column, strong bearing capacity, stable rise and fall, with fast rise, slow lock, fast fall function.
3. The surface temperature of the heating plate is uniform, the temperature control is accurate, the temperature controller can accurately display the temperature data, and the operation is safe and convenient.
4. Under a certain center distance, allow the installation of large diameter hydraulic cylinders, so as to reduce the number of hydraulic cylinders, and simple structure, less maintenance.
5. The oil pump motor stops working when the experimental material is pressed and formed, and has the function of automatic pressure compensation. Oil circuit configuration is more reasonable and reliable.
6. Exhaust time, exhaust times, heating temperature, pressure time can be set, easy to operate.
Application:
Mainly used in rubber and products, plastics and products PVC, pigments, masterbatches, stabilizers, and other industries, its main use is to test raw materials after molding, its physical properties change, contrast.
Such as: the surface gloss of the material after molding, whether there are black spots, its strength, hardness, plasticity and so on.
Colleges and universities, scientific research institutions: research and development of new materials, teaching use, formula comparison and improvement
Plastic industry: tablet proofing, fisheye, black spots, stains and other detection
Pigment industry: press, do contrast film
Stabilizer chemical industry: tablet, test strength, hardness
Rubber industry: vulcanizing agent
Parameter:
|
Capacity |
20T/30T ( can be adjust) |
|
Heating method |
heating tube heating (special) |
|
Temperature range |
room temperature ~300℃ |
|
Temperature control accuracy |
±3℃ |
|
Vacuum Brand |
German RIETSCHLE vacuum pump |
|
Vacuum |
800mbar |
|
Control interface |
PLC programmable color touch screen, man-machine interface molding process dynamic, temperature display, pre-pressure time, pressure time and pressure display can be visually displayed and monitored |
|
Temperature control mode |
P.I.D self-tuning mode with high-precision sensor, with automatic temperature compensation function, Ensure temperature balance |
|
Material |
high quality alloy steel (corrosion resistance, high temperature resistance, uniform heat conduction) |
|
Pressure plate size |
300×300mm |
|
Pressure plate surface |
mirror hard chrome treatment |
|
Working layers |
One working layer (heating layer) |
|
Pressure plate spacing |
0~150mm |
|
Casters |
Machine with brake casters, easy to move and fix |
|
Power |
8 kw |
|
Volume |
1000×600×1500(W×D×H)mm |
|
Power |
three-phase five-wire, AC380 |
|
Weight |
about 700kg |
