Application
The rotary cutting machine is suitable for various skeleton oil seals, frameless oil seals, various leather cups, pressing parts, and rubber and plastic products that are left and right circular and cannot be supported by soft materials
Characteristic
1. Reduce labor costs and improve the efficiency of trimming waste edges;
2. The repaired product has a higher surface finish;
Technical Parameters:
|
vacuum degree |
-0.093MPa |
|
Precision of main shaft |
radial runout≤0.01mm |
|
Lateral runout ≤0.02mm |
|
|
Rotating speed of main shaft |
0~3000r/min |
|
Cutting angle |
-10°~100° |
|
Cutting range |
Diameter: 5mm~250mm adjustable Flat cutting :0-160mm,can be customized for larger sizes |
|
Production efficiency |
225 pcs/minute (depending on product) |
|
Consumption amount of compressed air |
20L/min |
|
Air pressure |
0.5MPa~ 0.8 MPa |
|
Working vacuum degree |
-0.093MPa |
|
Power supply |
AC220V±5% |
|
Total power |
600W |
|
Equipment weight |
About 260kg |
|
Equipment dimension(L*W*H) |
1250*620*1350mm |
